Specification

Camera
Sensor: 1/1.7-inch CMOS
Effective Pixels: 48 MP

Lens
FOV: 155°
Equivalent Focal Length: 12.7 mm
Focal Length: 2.34 mm
Aperture: f/2.8
Focus Mode: FF
Focus Range: 0.6 m to ∞
ISO Range:
100-6400 (Auto)
100-25600 (Manual)

Shutter Speed
Video: 1/8000-1/50 s
Photo: 1/8000-1/50 s
Still Photography Mode

Single Shot
Max Image Size: 4000×3000
Photo Format: JPEG
Video Resolution
With DJI Goggles 2:
4K@30/50/60fps
2.7K@30/50/60/100/120fps
1080p@30/50/60/100/120fps

With DJI FPV Goggles V2:
4K@30/50/60fps
2.7K@30/50/60/100/120fps
1080p@30/50/60/100/120fps
Video Format: MP4
Max Video Bitrate: 150 Mbps
Color Mode: Standard
D-Cinelike
EIS

Supports RockSteady and HorizonSteady
Can be disabled
Distortion Correction
Supports Normal Mode, Wide Mode, and Ultra Wide Mode
Supported File System
exFAT (recommended)
FAT32
Gimbal
Mechanical Range
Tilt: -95° to 75°
Controllable Range
Tilt: -80° to +65°
Stabilization
Single-Axis (tilt)
Max Control Speed
60°/s
Angular Vibration Range
±0.01°
Electronic Roll Axis
Real-time screen correction is unavailable during recording, but can be applied to the footage recorded on the drone.
Aircraft
Model
QF2W4K
Takeoff Weight
Approx. 410 g
Dimensions (L×W×H)
180×180×80 mm
Diagonal Distance
120 mm
Max Ascent Speed
6 m/s (Normal Mode, Sport Mode)
Max Descent Speed
6 m/s (Normal Mode, Sport Mode)
Max Speed [1]
8 m/s (Normal Mode)
14 m/s (Sport Mode)
27 m/s (Manual Mode)
Maximum Takeoff Altitude
5000 m
Max Hover Time
Approx. 18 mins [2]
Max Flight Distance
11.6 km
Max Wind Speed Resistance
10.7 m/s (Level 5)
Operating Temperature Range
-10° to 40° C (14° to 104° F)
Transmission Power (EIRP)
FCC: < 33 dBm
CE: < 14 dBm
SRRC: < 30 dBm
Antennas
Dual Antennas, 2T2R
GNSS
GPS + Galileo + BeiDou
Hovering Accuracy Range
Vertical:
±0.1 m (with Vision Positioning)
±0.5 m (with GNSS Positioning)

Horizontal:
±0.3 m (with Vision Positioning)
±1.5 m (with GNSS Positioning)
Supported SD Cards
microSD (up to 256 GB)
Recommended microSD Cards
SanDisk Extreme U3 V30 A1 32GB microSDXC
SanDisk Extreme Pro U3 V30 A1 32GB microSDXC
Kingston Canvas Go!Plus U3 V30 A2 64GB microSDXC
Kingston Canvas React Plus U3 V90 A1 64GB microSDXC
Kingston Canvas React Plus U3 V90 A1 128GB microSDXC
Kingston Canvas React Plus U3 V90 A1 256GB microSDXC
Samsung PRO Plus U3 V30 A2 256GB microSDXC
Internal Storage
20 GB
Sensing System
Downward (Binocular Vision and ToF) [3]
ToF Effective Measurement Height: 10 m
Precise Hovering Range: 0.5-10 m
Vision Sensor Hovering Range: 0.5-20 m
Operating Environment
Diffuse reflective surfaces with a clear pattern > 20% (such as walls, trees, or people)
Adequate lighting (lux > 15, normal indoor lighting conditions)
Intelligent Flight Battery
Battery Capacity
2420 mAh
Voltage
14.76 V
Charging Voltage Limit
17 V
Type
Li-ion
Chemical System
LiNiMnCoO2
Energy
35.71 Wh@0.5C
Discharge Rate
Typical: 7C
Weight
Approx. 162 g
Charging Temperature Range
5° to 40° C (41° to 104° F)
Video Transmission
Communication Frequency
2.400-2.4835 GHz (RX only)
5.725-5.850 GHz (RX and TX) [4]
Communication Bandwidth
Max 40 MHz
Live View Quality and Latency [5]
With DJI FPV Goggles V2:
810p/120fps Video Transmission Quality: The video transmission latency is lower than 28 ms.
810p/60fps Video Transmission Quality: The video transmission latency is lower than 40 ms.

With DJI Goggles 2:
1080p/100fps Video Transmission Quality: The video transmission latency is as low as 30 ms.
1080p/60fps Video Transmission Quality: The video transmission latency is as low as 40 ms.
Max Video Transmission Bitrate [6]
50 Mbps
Max Video Transmission Range [7]
10 km (FCC), 2 km (CE), 6 km (SRRC)
Audio Transmission
N/A
DJI Goggles 2
Model
RCDS18
Weight
Approx. 290 g (headband included)
Dimensions (L×W×H)
With antennas folded: 167.40×103.90×81.31 mm
With antennas unfolded: 196.69×103.90×104.61 mm
Screen Size (single screen)
0.49-inch
Resolution (single screen)
1920×1080
Refresh Rate
Up to 100 Hz
Interpupillary Distance Range
56-72 mm
Diopter Adjustment Range
-8.0 D to +2.0 D
FOV (single screen)
51°
Communication Frequency
2.400-2.4835 GHz
5.725-5.850 GHz [4]
Transmission Power (EIRP)
2.4 GHz: < 30 dBm (FCC), < 20 dBm (CE/SRRC/KC)
5.8 GHz [4]: < 30 dBm (FCC), < 23 dBm (SRRC), < 14 dBm (CE/KC)
Wi-Fi Protocol
Wi-Fi 802.11b/a/g/n/ac
Wi-Fi Communication Frequency
2.400-2.4835 GHz
5.150-5.250 GHz (indoor use only) [8]
5.725-5.850 GHz [4]
Wi-Fi Transmission Power (EIRP)
2.4 GHz: < 20 dBm (FCC/CE/SRRC/KC)
5.1 GHz [8]: < 20 dBm (FCC/CE/KC)
5.8 GHz [4]: < 20 dBm (FCC/SRRC/KC), < 14 dBm (CE)
Bluetooth Protocol
Bluetooth 5.2
Bluetooth Communication Frequency
2.400-2.4835 GHz
Bluetooth Transmission Power (EIRP)
< 8 dBm
Max Video Transmission Bitrate [6]
50 Mbps
Video Recording Format
MOV
Supported Video and Audio Playback Formats
MP4 and MOV (video coding formats: H.264 and H.265; audio format: ACC, PCM)
Wi-Fi Wireless Streaming
Supports DLNA Protocol
Operating Temperature Range
-10° to 40° C (14° to 104° F)
Power Input
DJI Goggles 2 Battery
Supported SD Cards
microSD (up to 256 GB)
DJI Goggles 2 Battery
Capacity
1800 mAh
Voltage
7-9 V (1.5 A)
Type
Li-ion
Chemical System
LiNiMnCoO2
Energy
18 Wh
Charging Temperature Range
0° to 45° C (32° to 113° F)
Max Charging Power
12.6 W (5 V/2 A, 9 V/1.4 A)
Weight
Approx. 122 g
Dimensions (L×W×H)
73.04×40.96×26 mm
Operating Time
Approx. 2 hours
DJI FPV Goggles V2
Model
FGDB28
Weight
Approx. 420 g (headband and antennas included)
Supported Video and Audio Playback Formats
MP4, MOV, MKV (video coding format: H.264; audio formats: AAC-LC, AAC-HE, AC-3, MP3)
Operating Temperature Range
0° to 40° C (32° to 104° F)
Video Recording Format
MOV (video coding format: H.264)
FOV
30° to 54°, adjustable
Image Size: 50% to 100%
Communication Frequency
2.400-2.4835 GHz
5.725-5.850 GHz [4]
Max Video Transmission Bitrate [6]
50 Mbps
Dimensions (L×W×H)
Without antennas: 184×122×110 mm
With antennas: 202×126×110 mm
Transmission Power (EIRP)
2.400-2.4835 GHz
FCC: ≤ 28.5 dBm
CE: ≤ 20 dBm
SRRC: ≤ 20 dBm

5.725-5.850 GHz [4]
FCC: ≤ 31.5 dBm
CE: ≤ 14 dBm
SRRC: ≤ 19 dBm
Screen Size (single screen)
2-inch
Power Input
Dedicated DJI Goggles batteries
Supported SD Cards
microSD (up to 256 GB)
Communication Bandwidth
Max 40 MHz
Interpupillary Distance Range
58-70 mm
Refresh Rate
144 Hz
Screen Resolution
1440×810
DJI FPV Goggles V2 Battery
Weight
Approx. 119 g
Dimensions (L×W×H)
73.04×40.96×26 mm
Capacity
1800 mAh
Voltage
Max 9 V
Chemical System
LiNiMnCoO2
Type
Li-Po 2S
Energy
18 Wh
Charging Temperature Range
0° to 45° C (32° to 113° F)
Max Charging Power
10 W
Operating Time
Approx. 110 mins
DJI Motion Controller
Model
FC7BMC
Weight
Approx. 167 g
Communication Frequency
2.400-2.4835 GHz
5.725-5.850 GHz [4]
Transmission Power (EIRP)
2.4 GHz: ≤ 28.5 dBm (FCC), ≤ 20 dBm (CE/SRRC)
5.8 GHz [4]: ≤ 31.5 dBm (FCC), ≤ 19 dBm (SRRC), ≤ 14 dBm (CE)
Operating Temperature Range
-10° to 40° C (14° to 104° F)
Operating Time
Approx. 5 hours
DJI FPV Remote Controller 2
Model
FC7BGC
Weight
Approx. 346 g
Communication Frequency
2.400-2.4835 GHz
5.725-5.850 GHz [4]
Transmission Power (EIRP)
2.4 GHz: ≤ 28.5 dBm (FCC), ≤ 20 dBm (CE/SRRC)
5.8 GHz [4]: ≤ 31.5 dBm (FCC), ≤ 19 dBm (SRRC), ≤ 14 dBm (CE)
Dimensions (L×W×H)
190×140×51 mm
Operating Time
Approx. 9 hours
Operating Temperature Range
-10° to 40° C (14° to 104° F)
Charging Time
2.5 hours
