Imaging

Sensor Resolution Effective: 8.29 Megapixel

Image Sensor 1/2"-Type 3-Chip CMOS

Horizontal Resolution (TV Lines) 2000 TV Lines or More

Image Stabilization Optical in Integrated Lens

Built-In ND Filter Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters and a 2 to 7 Stop Electronic ND Filter

Capture Type Video Only

Exposure Control

Shutter Type Electronic Rolling Shutter

Shutter Speed 1/8000 to 1/24 Second

Gain -3 to 42 dB

Shutter Angle 5.6 to 360°

Sensitivity f/12 at 2000 lux 89.9% Reflectance (1080p59.94 in Standard Mode or 4K59.94 in High Sensitivity Mode)

f/13 at 2000 lux 89.9% Reflectance (1080p59.94 in Standard Mode or 4K59.94 in High Sensitivity Mode)

Signal-to-Noise Ratio 63 dB

Minimum Illumination 0.0013 Lux

White Balance 1500 to 50,000K

Presets: ATW, AWB, Set A, Set B

Lens

Focal Length 5.6 to 95.2mm (35mm Equivalent: 30.3 to 515mm)

Optical Zoom Ratio 17x

Maximum Aperture f/1.9

Minimum Aperture f/16

Minimum Focus Distance Wide: 5.1 cm

Telephoto: 80.0 cm

Filter Size 77 mm

Control Rings Focus, Zoom, Iris

Focus Control Autofocus, Manual Focus

Video Capture

Internal Recording Modes XAVC-I

3840 x 2160 at 23.98/25/29.97/50/59.94 fps [600 Mb/s]

1920 x 1080p at 23.98/25/29.97/50/59.94 fps [222 Mb/s]

1920 x 1080i at 50/59.94 fps [222 Mb/s]

1280 x 720 at 50/59.94 fps [222 Mb/s]

XAVC-L

3840 x 2160 from 1 to 59.94 fps [150 Mb/s]

1920 x 1080p from 1 to 59.94 fps [50 Mb/s]

1920 x 1080i at 50/59.94 fps [50 Mb/s]

1280 x 720 from 1 to 59.94 fps [50 Mb/s]

XAVC-L

1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 Mb/s]

1920 x 1080i at 50/59.94 fps [25 to 35 Mb/s]

MPEG HD422 4:2:2

1920 x 1080p from 1 to 29.97 fps [35 to 50 Mb/s]

1920 x 1080i at 50/59.94 fps [35 to 50 Mb/s]

1280 x 720 from 1 to 59.94 fps [35 to 50 Mb/s]

MPEG HD420 4:2:0

1920 x 1080p from 1 to 29.97 fps [35 Mb/s]

1920 x 1080i at 50/59.94 fps [35 Mb/s]

1440 x 1080i at 50/59.94 fps [35 Mb/s]

1280 x 720 from 1 to 59.94 fps [35 Mb/s]

DV 4:2:0 8-Bit

720 x 576i at 50 fps [25 Mb/s]

720 x 576p at 25 fps [25 Mb/s]

720 x 480i at 59.94 fps [25 Mb/s]

720 x 480p at 29.97 fps [25 Mb/s]

Fast-/Slow-Motion Support Yes

Built-In Microphone Type Stereo

Audio Recording XAVC: 4-Channel 24-Bit 48 kHz LPCM Audio

IP Streaming None

Interface

Media/Memory Card Slot Dual Slot: SxS

Video I/O 1 x BNC (Component) Output

1 x BNC (12G-SDI) Output

1 x HDMI Output

Audio I/O 2 x XLR 3-Pin Microphone Input

1 x 1/8" / 3.5 mm TRS Stereo Headphone Output

Other I/O 1 x BNC (Timecode) Input

1 x BNC (Timecode) Output

1 x BNC (Genlock) Input

1 x 2.5 mm Sub-Mini (LANC) Control

1 x Micro-USB Data

1 x USB-A

1 x USB-C

1 x RJ45 (LAN) Data

Wireless 2.4 / 5 GHz Wi-Fi 5 (802.11ac), NFC

Mobile App Compatible Yes: Android & iOS

*As of June, 2023: Check with manufacturer for the most up-to-date compatibility

Global Positioning (GPS, GLONASS, etc.) GPS

Monitor

Size 3.5"

Resolution 2,360,000 Dot

Display Type Articulating LCD

Viewfinder

Type Built-In Electronic (OLED)

Size 0.5"

Resolution 2,360,000 Dot

Focus

Focus Type Auto and Manual Focus

Focus Mode Automatic, Manual Focus

Environmental

Operating Temperature 32 to 72°F / 0 to 40°C

Storage Temperature -4 to 140°F / -20 to 60°C

General

Battery Type Sony BP-U Series

Accessory Mount 1 x Intelligent Hot Shoe

Dimensions (W x H x D)  178.4 x 202 x 426.3 mm (With Protrusions)

Weight 3 kg
