Key Specs

Wireless Technology

Analog UHF

Included Transmitters

1 x Bodypack

Diversity

True Diversity

Max Operating Range

330' / 100.6 m (Line of Sight)

Receiver Type

Tabletop

Microphone Type

Lavalier

Polar Pattern

Omnidirectional

System

Wireless Technology

Analog UHF

Number of RF Channel Frequencies

1840

Included Transmitters

1 x Bodypack

Diversity

True Diversity

RF Frequency Band

A1: 470 to 516 MHz

RF Bandwidth

46 MHz

Frequency Step Size

25 kHz

Max Operating Range

330' / 100.6 m (Line of Sight)

Max Transmitters per Band

20

Deviation

±24 kHz (Peak)

Modulation

Wideband FM

Receiver

Receiver Type

Tabletop

Mounting Options

Rackmount (with Included Hardware)

Rackmount Size

1 RU (1/2 Rack)

Antenna

2 x Rod, Detachable (Rear-Mount)

Number of Audio Channels

1

Audio I/O

1 x XLR 3-Pin Male Balanced Output

1 x 1/4" TRS Female Unbalanced Output

Gain Range

48 dB (3 dB Steps)

Audio Output Level

XLR Output:

+18 dBu (Balanced)

1/4" Output:

+12 dBu (Unbalanced)

Network I/O

2 x RJ10

Network Protocols

Manual IP

Squelch

Adjustable, 5 to 25 dBμV

Adjacent Channel Isolation

>65 dB

Power Requirements

AC/DC Power Adapter

AC/DC Power Adapter

12 VDC at 300 mA (Included)

AC Input Power

100 to 240 VAC, 50 / 60 Hz at 0.2 A

Display & Indicators

1 x Backlit LCD (AF Level, Channel, Frequency, Mute, RF Level, Transmitter Battery Status)

Housing

Metal

Operating Temperature

14 to 131°F / -10 to 55°C

Dimensions

8.3 x 1.7 x 7.5" / 212 x 43 x 190 mm

Weight

2.2 lb / 980 g

Transmitter

Transmitter Type

Bodypack

RF Output Power

30 mW

Audio I/O

1 x 1/8" / 3.5 mm TRS Female Input (Lockable)

Muting

Mute Switch

Audio Input Level

3 V RMS

Gain Range

60 dB (3 dB Steps)

Frequency Response

80 Hz to 18 kHz (Mic)

25 Hz to 18 kHz (Line)

Sync Method

IR

Antenna

1 x Flexible Whip, Fixed (Beltpack)

Power Requirements

Battery

Battery Type

2 x AA (Included)

1 x Sennheiser Battery Pack (Not Included, Replaceable)

Approx. Battery Life

8 Hours (Alkaline)

Display & Indicators

1 x Backlit LCD (Audio Level, Battery Status, Channel, Group, Mute, Signal Strength)

Housing

Metal

Operating Temperature

14 to 131°F / -10 to 55°C

Dimensions

2.5 x 3.2 x 0.9" / 64 x 82 x 24 mm

Weight

5.6 oz / 160 g (with Batteries)

Microphone

Microphone Type

Lavalier

Color

Black

Sound Field

Mono

Capsule

Electret Condenser

Polar Pattern

Omnidirectional

Frequency Range

50 Hz to 18 kHz

Equivalent Noise Level

36 dB

Maximum SPL

130 dB SPL Peak

Sensitivity

20 mV/Pa

Output Connector

1 x 1/8" / 3.5 mm TRS Male Unbalanced (Lockable)

Cable Length

5.25' / 1.6 m

Operating Voltage

7.5 V

Diameter

0.41" / 10.5 mm

Packaging Info

Package Weight

6.02 lb

Box Dimensions (LxWxH)

16.15 x 12.7 x 3.6"
