Key Specs

Sensor Resolution
Actual: 13.4 Megapixel (4268 x 3148)
Effective: 8.29 Megapixel (3840 x 2160)
Image Sensor
1"-Type CMOS
Image Stabilization
Optical in Integrated Lens
Digital

Internal Recording Modes
MXF/XF-AVC 4:2:2 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [160 to 410 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 to 310 Mb/s]
1920 x 1080i at 50/59.94 fps [50 to 160 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps
H.265/MP4 4:2:2 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [135 to 225 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps [12 Mb/s]
H.265/MP4 4:2:0 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 170 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps [9 Mb/s]
H.264/MP4 4:2:0 8-Bit
3840 x 2160 from 1 to 23.98/25/29.97/50/59.94 fps [150 Mb/s]
1920 x 1080p from 1 to 23.98/25/29.97/50/59.94 fps [35 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps

External Recording Modes
SDI/BNC
UHD 4K (3840 x 2160) up to 59.94 fps
Media/Memory Card Slot
Slot 1: SD/SDHC/SDXC
Slot 2: SD/SDHC/SDXC
Video I/O
1x HDMI 2.0 Output
1x BNC (12G-SDI) Output
Battery Type
Canon BP-A Series

Imaging
Sensor Resolution
Actual: 13.4 Megapixel (4268 x 3148)
Effective: 8.29 Megapixel (3840 x 2160)
Image Sensor
1"-Type CMOS
Image Stabilization
Optical in Integrated Lens
Digital
Built-In ND Filter
Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
Capture Type
Stills & Video
Exposure Control
Shutter Type
Electronic Rolling Shutter
Shutter Type
Electronic Rolling Shutter
Shutter Speed
1/2000 to 1/4 Second
Shutter Angle
11 to 360°
Sensitivity
f/12 at 2000 lux
Minimum Illumination
1.5 Lux at 1/30 Shutter Speed
Lens
Focal Length
8.3 to 124.5mm (35mm Equivalent: 25.5 to 382.5mm)
Optical Zoom Ratio
15x
Max Digital Zoom
30x ( in 1080p)
Maximum Aperture
f/2.8
Minimum Aperture
f/4.5
Optical Design
18 Elements in 14 Groups
Minimum Focus Distance
Entire Zoom Range: 2.0' / 60.0 cm
Wide: 0.4" / 1.0 cm
Filter Size
58 mm
Control Rings
Focus
Zoom
Iris
Focus Control
Autofocus
Manual Focus
Video Capture
Internal Recording Modes
MXF/XF-AVC 4:2:2 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [160 to 410 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 to 310 Mb/s]
1920 x 1080i at 50/59.94 fps [50 to 160 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps
H.265/MP4 4:2:2 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [135 to 225 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/120 fps [50 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps [12 Mb/s]
H.265/MP4 4:2:0 10-Bit
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [100 to 170 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94 fps [35 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps [9 Mb/s]
H.264/MP4 4:2:0 8-Bit
3840 x 2160 from 1 to 23.98/25/29.97/50/59.94 fps [150 Mb/s]
1920 x 1080p from 1 to 23.98/25/29.97/50/59.94 fps [35 Mb/s]
1280 x 720 at 23.98/25/29.97/50/59.94 fps
External Recording Modes
SDI/BNC
UHD 4K (3840 x 2160) up to 59.94 fps
Fast-/Slow-Motion Support
Yes
Gamma Curve
Canon Log 3, HDR-HLG
Built-In Microphone
Stereo
Audio Recording
2-Channel 16-Bit 48 kHz AAC Audio
4-Channel 24-Bit 48 kHz LPCM Audio
IP Streaming
MPEG2
1920 x 1080 to 3840 x 2160 at 25p, 29.97p, 50p, 59.94p (4.0 to 16.0 Mb/s)
1920 x 1080 at 50i, 59.94i (4.0 to 9.0 Mb/s)

Interface
Media/Memory Card Slot
Slot 1: SD/SDHC/SDXC
Slot 2: SD/SDHC/SDXC
Video I/O
1x HDMI 2.0 Output
1x BNC (12G-SDI) Output
Audio I/O
2x XLR 3-Pin Input
1x 1/8" / 3.5 mm TRS Stereo Input
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O
1x Barrel (24VDC) Input
Other I/O
1x USB-A Output
1x USB-C
1x BNC (Genlock, Sync) Input/Output
1x BNC (Timecode) Input/Output
1x 2.5 mm Sub-Mini Control
1x D-Sub 8-Pin Control
1x RJ45 (LAN) Input/Output
Wireless
2.4 / 5 GHz MIMO Wi-Fi Video Output, Audio Output, Control
Global Positioning (GPS, GLONASS, etc.)
No
Viewfinder
Type
Removable Electronic (OLED)
Size
0.36"
Resolution
1,770,000 Dot
Focus
Focus Type
Auto and Manual Focus
Focus Mode
Automatic, Manual Focus

Environmental
Operating Temperature
32 to 104°F / 0 to 40°C
Operating Humidity
0 to 85%

General
Battery Type
Canon BP-A Series
Power Consumption
21.5 W
Tripod Mounting Thread
1/4"-20 Female
3/8"-16 Female
Accessory Mounting Thread
1 x
1 x
Built-In Video Light
Yes (Infrared)
Dimensions (W x H x D)
15.2 x 8.6 x 8.3" / 385 x 219 x 210 mm (With Protrusions)
13.1 x 6.8 x 6.6" / 333 x 173 x 168 mm (Without Protrusions)
Weight 4.4 lb / 2010 g
