Specs

Image sensor
Type: Approx 22.3mm x 14.9mm CMOS
Effective number of pixels: About 24.1 megapixels
Total number of pixels: About 24.7 megapixels
Aspect ratio: 3:2
Low pass filter: Built-in/fixed
Cleaning the sensor: Manual cleaning and data collection for dust elimination
Color filter type: RGB primary colors

Image processor
Type: DIGIC 4+

Objective
Lens mount: EF/EF-S
Focal length: Equivalent to 1.6x the focal length of the lens
BS: Optical Image Stabilizer is provided on compatible lenses

Focusing
Type: Via optical viewfinder:
TTL registration in secondary image, phase difference detection system with special AF sensor
Via Live View on the LCD screen:
AF with contrast detection
AF system/points:
Via optical viewfinder: 9 AF points (f/5.6 cross type at center)
AF workspace:
Via optical viewfinder:
Central AF point: EV 0–18 (at room temperature and ISO100)
Other AF points: EV 1– 18 (at room temperature and ISO100)
Via Live View on the LCD screen:
EV 1–18 (at room temperature and ISO100)
AF method:
Via optical viewfinder:
AI Focus (automatically switches between One-Shot AF and AI SERVO AF)
One Shot AF< a i=3>AI ServoManualVia Live View on the LCD screen:
One Shot AF (contrast detection AF)
Quick mode (via phase detection AF sensor)
Manual

Exposure setting
Measurement methods:
Via optical viewfinder:
Evaluative via 63-zone Dual Layer metering sensor (linked to all AF points)
Partial (center, approx. 10 % of viewfinder)
Center-weighted average available
Via Live View on the LCD screen:
Evaluative light metering (315 zones) a>
Measurement range:
Via optical viewfinder:
EV 1–20 (at room temperature, ISO 100, with evaluative metering)
Via Live View on the LCD screen:
EV 0–20 (at room temperature, ISO 100, with evaluative light metering)
AE lock:
Automatic: With the 1-shot AF method and evaluative metering,
the exposure is locked when the focus is set.
Manual: With automatic lock button for shooting methods in the creative zone.
Exposure compensation: +/-5 EV in 1/3 or 1/2 steps (
can be combined with automatic exposure variation).
Automatic exposure variation: 3 shots +/-2 EV, 1/2 or 1/3 steps
ISO sensitivity:
AUTO (100-6400),
100-6400 (in 1 step)
ISO expandable to H: 12800 1
During movie recording: Auto (100-6400), 100-6400 (in whole steps)

Shutter
Type:
Electronically controlled curtain shutter, with electronic first curtain
Speed:
30-1/4000 sec (in 1/2 or 1/3 steps),
Bulb (Total shutter speed range. Available range varies by shooting method)

White balance
Type: Automatic white balance with the image sensor
Settings:
AWB (Ambient Priority/White Priority),
Daylight, Shadow, Cloudy, Electric Light,
White Fluorescent Light, Flash, Native (Approx. 2000-10000K)
White Balance Compensation:Magenta/green +/-9.
Blue/yellow +/-9
Own white balance: Yes, 1 setting can be registered
White balance variation:
+/-3 levels in single steps
3 varied images per press.
Adjustable blue/yellow or magenta/green gain.< /span>

View-finder
Type: Penta mirror
Coverage (vertical/horizontal): About 95%
Magnification: About 0.80x 2
Eye distance: About 21 mm (from the center of the eyepiece lens)
Diopter adjustment: -2.5 to +0.5 m-1 (diopter)
Focusing disc: Fixed
Mirror: Quick-retracting semi-transparent mirror
Preview depth of field: Yes, assigned to the SET button
Eyepiece cap: On the strap

LCD monitor
Type: 7.5 cm (3.0 in) TFT LCD, approximately 920,000 dots
Coverage: About 100%
Viewing angle (horizontal/vertical): About 170°
Brightness adjustment: Adjustable to one of seven levels
Display options:
Quick Control Window
Camera Settings

Flash
Guide number for built-in flash: 9.2
Flash coverage for built-in flash:
Up to 17mm focal length (35mm equivalent: 28mm)
Charging time for built-in flash: About 2 seconds
The location: Auto, Manual flash on/off
Reduction of red eyes: Yes - with red-eye reduction lamp
Flash sync:
Cameras manufactured before September 2020 are not equipped with an X connector3,
max. flash sync time: 1/200 sec. with compatible Speedlites
Flash exposure compensation: +/- 2 EV in 1/2 or 1/3 steps
Flash exposure lock: Yes
Synchronization with the second curtain: Yes
Lightning shoe/PC connector: Yes No
Compatibility with external flash: E-TTL II with EX-series Speedlites 3
Control of external flash:
Available via the camera's menu screen, except in settings for wireless,
radio-controlled flash photography

Photographing
The location:
Smart Scene Mode, No Flash, Creative Auto Mode, Portrait, Landscape, Close-up,
Sports, Food, Night Portrait, Movie, Program Auto, Aperture Priority AE, Aperture Priority AE, Manual
Image styles:
Auto, Standard, Portrait, Landscape, Neutral, Lifelike, Monochrome, Custom (x3)
Color space: sRGB and Adobe RGB
Image processing:
Highlight priority
Auto exposure correction (4 settings)
Noise reduction for long exposure time
Noise reduction for high ISO (4 settings )
Automatic lens peripheral lighting correction (up to 36 lens profiles can be registered in the camera)
Creative filters (Grainy black and white, Soft focus, Toy camera, Miniature effect, Fisheye effect) - only when displaying images
Feeding methods: Single Shot, Burst, Self Timer (2s, 10s, 10s + Burst 2-10)
Serial shooting: Max. About 3 b/s for about 150 JPEG images4, 11 RAW images5< a i=4>6

Live View mode
Coverage: About 100% (horizontal and vertical)
Frame rate: 29.97 bps
Focusing:
Live mode: One Shot AF (contrast detection AF)
Quick mode: One Shot AF (phase detection AF sensor)
Manual (magnification with 5x or 10x is available)
Measurement method:
Evaluative measurement in real time with the image sensor
Active measurement time can be changed
Display options: Grid (x2), histogram

File format
Still image format:
JPEG: fine, normal (according to Exif 2.30)/Design rule for Camera File system (2.0),
RAW: RAW (14 bits, Canon original RAW 2nd edition) ,
Digital Print Order Format [DPOF] Version 1.1 Compliant
Simultaneous recording with RAW+JPEG: Yes, RAW + large JPEG
Image format:
JPEG 3:2: (L) 6000 x 4000, (M) 3984 x 2656, (S1) 2976 x 1984, (S2) 1920 x 1280, (S3) 720 x 480
JPEG 4:3: (L) 5328x4000, (M) 3552x2664, (S1) 2656x1992, (S2) 1696x1280, (S3) 640x480
JPEG 16:9: (L) 6000x3368, (M) 3984x2240, (S1) 2976x1680 (S2) 1920x1080, ( S3) 720 x 408
JPEG 1:1: (L) 4000 x 4000, (M) 2656 x 2656, (S1) 1984 x 1984, (S2) 1280 x 1280, ( S3) 480x480
RAW: (RAW) 6000x4000
Movie type: MOV (Video: H.264 inter frame (IPB),
Audio: linear PCM, recording level can be manually adjusted by the user)
Movie format:
1920x1080 (30, 25, 24fps)
1280x720 (60, 50fps)
640 x 480 (30, 25 fps)
Stage length: Max. duration 29 min 59 sec, max. file size 4 GB

Power source
Batteries: 1 rechargeable lithium ion battery LP-E10
Battery capacity:
About 500 (at 23°C, AE 50%, FE 50%)11
About 410 (at 0°C, AE 50 %, FE 50%)
Battery indicator: 4 levels
Power saving function:
The power turns off after 30 seconds or after 1, 2, 4, 8 or 15 minutes.
Power sources and battery chargers:
Battery charger LC-E10E
Compact power supply CA-PS700 Power adapter DR-E10
