RODE RODECaster DUO Specs

Channels of I/O 2 Inputs / 4 Outputs

Built-In DSP Yes

Maximum Sampling Rate 48 kHz / 24-Bit

Number of Microphone Inputs 2

Number of Headphone Mixes 1 x Master

Analog Audio I/O

2 x Combo XLR-1/4" TRS Mic/Line Input

2 x 1/4" TRS Line Output

2 x 1/4" TRS Headphone Output

Host Connection 2 x USB-C

OS Compatibility macOS

Windows *As of April, 2023: Check with manufacturer for the most up-to-date compatibility

Power Requirements AC/DC Power Adapter (Included)

Channels of I/O 2 Inputs / 4 Outputs

Built-In DSP Yes

Maximum Sampling Rate 48 kHz / 24-Bit

Number of Microphone Inputs 2

Built-In Microphone No

Number of Headphone Mixes 1 x Master

Expansion Slots No

Signal Processing Pad No

Gain/Trim Range -135 +76 dB

High-Pass Filter No

Solo/Mute Solo, Mute per Input Channel

Connectivity Analog Audio I/O

2 x Combo XLR-1/4" TRS Mic/Line Input

2 x 1/4" TRS Line Output

2 x 1/4" TRS Headphone Output

Phantom Power No

Digital Audio I/O No

Host Connection 2 x USB-C

Host Connection Protocol USB 3.0 / 3.1/3.2 Gen 1

USB (Non-Host)

No

MIDI I/O No

Wireless Bluetooth

Digital Audio Sample Rates 48 kHz

Bit Depths 24-Bit

Sync Sources No Audio Storage & Playback

Media/Memory Card Slot Single Slot: microSD/microSDHC

Compatibility OS Compatibility macOS Windows

Included Software No

Mobile Device Compatibility No

Power

Power Requirements

AC/DC Power Adapter (Included)

AC/DC Power Adapter

5 V

Specifications Rode PSA1 Studio Arm

Form Factor Studio Microphone Arm with Mount

Color Black

Total Reach  82 cm

Boom Angle Adjustable

Rotation Range 360°

Load Capacity 0.7 to 1.1 kg

Cable Management External Cable Clip

Mount Hole Diameter  22 mm

Mounting Type C-Clamp (Included)

Surface Mount (Included)

Clamp Range  55.00 mm


Designed for RØDE Procaster, Podcaster and PodMic models, the PSA1 supports most microphones weighing between 700 g  and 1.1 kg when combined with compatible shock mounts.

XLR Cable 5M Specs

Connector 1 1x XLR 3-Pin Male Straight

Connector 2 1x XLR 3-Pin Female Straight

Contact Plating Silver

Wire Gauge 24 AWG

Shielded Yes

Color Black

Headset Specs

LED light on sides

Frequency: 20-20000Hz

Sensitivity: 100dB+/- 3dB

Rated power: 20mW

Max input power: 30mW

Cord length: approximately 2.1 meter

Driver unit: 50mm

Microphone sensitivity: -42dB+/-3dB

RODE PodMic Specs

Key Specs

Element Type Dynamic

Polar Pattern Cardioid

Frequency Range 20 Hz to 20 kHz

Output Connector 1 x XLR 3-Pin

Microphone Primary Applications

Broadcast, Podcast Intended Sound Sources

Vocals

Sound Field Mono

Element Type Dynamic

Polar Pattern Cardioid

Circuitry Solid-State

Pad None

High-Pass Filter None

Tone Adjustment None

Gain Adjustment None

Performance

Frequency Range 20 Hz to 20 kHz

Impedance 32 Ohms

Sensitivity Cardioid: -57 dB at 1 kHz

Connectivity

Output Connector 1 x XLR 3-Pin

Headphone Connector None

Physical

Mounting Mounting Thread (via Integrated Hardware)

Mounting Thread Size 5/8"-27 Female

Included Case None

Included Filters None

Dimensions ø: 10.9 x L: 17.2 cm

Weight 937 g
