Specifications
Wireless Technology Digital 2.4 GHz
Diversity Non-Diversity
Max Operating Range
820.2' / 250 m (Line of Sight)
Receiver Type 1x Camera-Mount
Number of Audio Channels 2
Included Transmitters 1x Clip-On
Microphone Type
1x Built-In (Clip-On Transmitter)

System
Wireless Technology Digital 2.4 GHz
Diversity Non-Diversity
RF Frequency Band
2400 to 2483.5 MHz
Max Operating Range
820.2' / 250 m (Line of Sight)
Max Transmitters per Band 2
Encryption Proprietary
Built-In Recorder
Yes (on Transmitter via Built-In Storage)
Timecode Support No
Mobile App Compatible
Yes: Android & iOS
App Name: DJI Mimo

Receiver
Receiver Type 1x Camera-Mount
Mounting Options
Shoe-Mount (with Included Hardware)
Antenna 1x Internal
Number of Audio Channels 2
Audio I/O
1x 1/8" / 3.5 mm TRS Unbalanced Output
1x 1/8" / 3.5 mm TRS Headphone Output
Network I/O No
Word Clock I/O No
USB/Lightning Connectivity
1x Lightning Male (Audio)
1x USB-C Male (Audio)
Standalone Audio Interface Capable
Frequency Response
50 Hz to 20 kHz
Display OLED Touchscreen
Power Requirements Battery

Transmitters
Included Transmitters
1x Clip-On
RF Output Power 100 mW
Antenna Internal
Input Level Microphone
Audio I/O
1x 1/8" / 3.5 mm TRS Female Input
USB I/O
1x USB-C
Muting No
Auto-Level/Gain No
Frequency Response
50 Hz to 20 kHz
Sync Method
Proprietary Display
Single-LED Indicators Only

Microphones
Microphone Type
1x Built-In (Clip-On Transmitter)
Polar Pattern
Omnidirectional
Frequency Response
50 Hz to 20 kHz (Low Cut Off)
100 Hz to 20 kHz (Low Cut On)
Maximum SPL 120 dB
Color  Black

Power
Receiver Battery Type
1x Built-In Rechargeable - 360 mAh
Receiver Battery Life
6 Hours (Lithium Rechargeable)
Transmitter Battery Type
1x Built-In Rechargeable - 360 mAh
Transmitter Battery Life
6 Hours
Battery Charging Time
70 Minutes

Physical
Environmental Resistance No
Dimensions
Receiver:
2.1 x 1.1 x 0.9" / 54.2 x 28.4 x 22.5 mm
Transmitter:
1.8 x 1.2 x 0.9" / 46.1 x 31 x 21.8 mm
Weight
Receiver:
1 oz / 28 g
Transmitter:
1 oz / 28 g
Microphone:Not Specified

Packaging Info
Package Weight 0.47 lb
Box Dimensions (LxWxH)
4.9 x 4.6 x 1.7"
