Form Factor Desktop

Display None

Channels of I/O Analog:

2 Inputs / 4 Outputs

Maximum Sampling Rate 96 kHz / 24-Bit

Number of Microphone Preamps 2 Preamps

Built-In Microphone Yes

Input Level Adjustment 2 x Knob

Signal Processing

Pad None

Gain/Trim Range Mic/Hi-Z Inputs:

45 dB

High-Pass Filter None

Connectivity

Analog Audio I/O 2 x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Hi-Z Input

2 x RCA Coaxial Unbalanced Line Output

1 x 1/8" / 3.5 mm TRS Unbalanced Aux Input

1 x 1/8" / 3.5 mm TS Unbalanced Mic Input (Front Panel)

1 x 1/8" / 3.5 mm TRRS Unbalanced Headphone/Headset In/Out (Front Panel)

1 x 1/4" TRS Unbalanced Headphone Output (Front Panel)

Phantom Power 48 V, Selectable On/Off (Selectable on Individual Inputs)

Digital Audio I/O None

Host Connection / USB 1 x USB-B

Host Connection Protocol USB 2.0

USB (Non-Host) 1 x Micro-USB (Power Input)

Sync I/O None

Network I/O None

MIDI I/O None

Performance

Frequency Response Line Outputs:

20 Hz to 20 kHz +0/-1 dB (at 44.1/48 kHz)

20 Hz to 40 kHz +0/-1 dB (at 88.2/96 kHz)

1/4" Headphone Outputs:

20 Hz to 20 kHz +0/-3 dB (at 44.1/48 kHz)

20 Hz to 40 kHz +0/-3 dB (at 88.2/96 kHz)

Maximum Input Level +7.7 dBV

Maximum Output Level Line Outputs:

+6 dBV

Headphone Output Power 15 mW per Channel into 32 Ohms

Impedance XLR Mic Inputs:

2.4 Kilohms

1/8" / 3.5 mm Mic Inputs:

≥ 5 Kilohms

1/8" / 3.5 mm Aux Inputs:

≥ 5 Kilohms

Line Outputs:

≥ 200 Ohms

Hi-Z Inputs:

≥ 1 Megohms

SNR Mic Inputs:

100 dB

THD Mic Inputs:

≤ 0.005% (1 kHz)

Crosstalk Mic Inputs:

95 dB (1 kHz)

EIN Mic Inputs:

< -120 dB (150-Ohm Source)

Digital Audio

Sample Rates 44.1 / 48 / 88.2 / 96 kHz

Bit Depths 16 / 24-Bit

Audio Storage & Playback

Memory Card Slot None

Compatibility

OS Compatibility Windows 7

Windows 8.1

Windows 10

macOS 10.9 or Later

iOS 7 or Later

iPadOS

*As of June, 2022: Check with manufacturer for the most up-to-date compatibility

Included Software None

Processor Requirement 2 GHz

RAM Requirements 2 GB

Mobile Device Compatibility iPhone, iPad

Required Hardware Available USB 2.0 Port

Internet Connection Required for Software/Driver Download

Power

Power Requirements DC Input or USB Bus Power

AC/DC Power Adapter 5 VDC (Not Included)

Power Consumption 1.5 W

Physical

Anti-Theft Features Kensington Security Slot
