SPECIFICATIONS

Lens Mount Nikon Z

Sensor Resolution

Effective: 24.5 Megapixel (6048 x 4032)

Image Sensor

35.9 x 23.9 mm (Full-Frame) Partially Stacked CMOS

Sensor Crop (35mm Equivalent)

Crop Factor: 1x *Additional Crop Occurs in Select Video Modes

Image Stabilization

Sensor-Shift, 5-Axis

Built-In ND Filter

No

Capture Type

Stills & Video

EXPOSURE CONTROL

Shutter Type

Mechanical Focal Plane Shutter and Electronic Rolling Shutter

Shutter Speed

Electronic Shutter Up to 1/16000 Second

Bulb/Time Mode

Bulb Mode, Time Mode

ISO Sensitivity Range

100 to 64,000

Metering Method

Center-Weighted Average, Highlight Weighted, Matrix, Spot

Exposure Modes

Aperture Priority, Auto, Manual, Program, Shutter Priority

Exposure Compensation

-5 to +5 EV (1/3, 1/2 EV Steps)

Metering Range

-4 to 17 EV

Continuous Shooting

Mechanical Shutter Up to 14 fps at 24.5 MP (Raw) Electronic Shutter Up to 60 fps at 24.5 MP Electronic Shutter Up to 120 fps for up to 1000 Frames (JPEG)

Interval Recording

Yes

Self-Timer

2/5/10/20-Second Delay

STILL IMAGE CAPTURE

Image Sizes

3:2 JPEG / Raw 24.5 MP (6048 x 4032)

Aspect Ratio

3:2

Image File Format

JPEG, Raw

Bit Depth

14-Bit

VIDEO CAPTURE

Internal Recording Modes

Raw 6048 x 3404 up to 59.94 fps ProRes RAW 6048 x 3404 up to 59.94 fps

External Recording Modes

HDMI UHD 4K (3840 x 2160)

Fast-/Slow-Motion Support

Slow-Motion Only

Gamma Curve

HDR-HLG, Nikon N-Log

Recording Limit

No

IP Streaming

No

Built-In Microphone

Stereo

Audio Recording

AAC Audio 2-Channel LPCM Audio

INTERFACE

Media/Memory Card Slot

Slot 1: CFexpress Type B / XQD Slot 2: SD/SDHC/SDXC (UHS-II)

Video I/O

1x HDMI (Unspecified Signal) Input

Audio I/O

1x 1/8" / 3.5 mm TRS Stereo Headphone Output 2x 1/8" / 3.5 mm TRS Stereo Microphone Input

Power I/O

1x USB-C Input

Other I/O

1x USB-C Data Input (Shared with Power Input) 1x Nikon DC2

Wireless

2.4 / 5 GHz Wi-Fi 5 (802.11ac) Bluetooth 5.0

Mobile App Compatible

Yes: Android & iOS

Global Positioning (GPS, GLONASS, etc.)

GPS

MONITOR

Display Size

3.2"

Resolution

2,100,000 Dot

Display Type

Tilting Touchscreen LCD

Secondary Display

Top: Status Display

VIEWFINDER

Type

Built-In Electronic

Size

0.5"

Resolution

5,760,000 Dot

Eye Point

21 mm

Coverage

100%

Magnification

Approx. 0.8x

Diopter Adjustment

-4 to +2

FOCUS

Focus Type

Auto and Manual Focus

Focus Mode

Continuous-Servo AF, Full-Time Servo, Manual Focus, Single-Servo AF

Autofocus Points

Photo, Video493

Autofocus Sensitivity

-10 to +18 EV

FLASH

Built-In Flash/Light

No

Flash Modes

First-Curtain Sync, Off, Rear Curtain/Slow Sync, Rear Sync, Red-Eye Reduction, Slow Sync, Slow Sync/Red-Eye Reduction

Maximum Sync Speed

1/200 Second

Flash Compensation

-3 to +1 EV (1/3, 1/2 EV Steps)

Dedicated Flash System

iTTL

External Flash Connection

Shoe Mount

ENVIRONMENTAL

Operating Temperature

32 to 104°F / 0 to 40°C

Operating Humidity

0 to 85%

GENERAL

Battery Type

1x EN-EL15c Rechargeable Lithium-Ion

Shoe Mount

1x Hot Shoe

Tripod Mounting Thread

1x 1/4"-20 Female

Material of Construction

Magnesium Alloy

Dimensions (W x H x D)

5.5 x 4 x 2.9" / 138.5 x 101.5 x 74 mm

Weight

23.6 oz / 670 g (Body Only)

NIKON NIKKOR Z 24-70MM F/4 S LENS SPECS

Maximum Aperture

f/4

Minimum Aperture

f/22

Lens Mount Type

Nikon Z

Lens Format Coverage

Full-Frame

Angle of View

84° to 34° 20'

Minimum Focus Distance

11.81" / 30 cm

Maximum Magnification

0.3x

Optical Design

14 Elements in 11 Groups

Diaphragm Blades

7, Rounded

Focus Type

Autofocus

Image Stabilization

No

Filter Size

72 mm (Front)

Dimensions (ø x L)

3.05 x 3.48" / 77.5 x 88.5 mm

Length at Maximum Extension

5.44" / 138.2 mm

Weight

1.1 lb / 500 g
