Specifications

System
Wireless Transmission Digital 2.4 GHz
Number of RF Channels 18
Included Transmitters 1 x Clip-On with Microphone
Diversity Non-Diversity
RF Frequency Band 2400 to 2483.5 MHz
RF Bandwidth Up to 83.5 MHz
Max Operating Range
50 m (Line of Sight)
30 m (with Obstruction)
Max Systems per Setup 18
Sample Rate/Resolution 48 kHz / 24-Bit
Latency 12 ms
Encryption None
Modulation GFSK

Receiver
Form Factor Beltpack / Camera-Mount / Portable
Mounting Options Belt Clip, Shoe-Mount (with Included Hardware)
Antenna 1 x 1/4 Wave Wire, Fixed
Number of Audio Channels 2
Audio I/O 1 x 1/8" / 3.5 mm TRS Female Unbalanced Line Output
Audio Output Level 5 dB
Phantom Power Protection None
Frequency Response 20 Hz to 16 kHz
Network I/O None
Word Clock I/O None
USB/Lightning Connectivity 1 x USB Type-C (Bus Power, Charging)
Power Requirements Battery or Bus Power (USB)
Battery Type 1 x Built-In Rechargeable (Included, Not Replaceable)
Internal Battery Capacity 400 mAh
Battery Charging Time 2.5 Hours
Approx. Battery Life 5 Hours
Display & Indicators 1 x LED (Battery Status, Power, Recharging, Sync)
Housing ABS, Plastic
Operating Temperature  0 to 50°C
Storage Temperature  -20 to 50°C
Dimensions 6.2 x 3.3 x 1.5 cm
Weight 31 g

Transmitter 1
Transmitter
Form Factor Clip-On with Microphone
RF Output Power 10 mW
Audio I/O 1 x 1/8" / 3.5 mm TRS Female Unbalanced Input
Plug-In Power 1 V
Pad None
Muting None
Audio Input Level -42 to -30 dBV (at 0 dB Gain)
Gain Range +11 to +25 dB (7 dB Steps)
Signal Processing None
Frequency Response 20 Hz to 16 kHz
Sync Method IR
Antenna 1 x 1/4 Wave Wire, Fixed
Power Requirements Battery or Bus Power (USB)
Battery Type 1 x Built-In Rechargeable (Included, Not Replaceable)
Internal Battery Capacity 400 mAh
Battery Charging Time 1.5 to 2.5 Hours
Approx. Battery Life 5 Hours
USB/Lightning Connectivity 1 x USB Type-C (Bus Power, Charging)
Display & Indicators
4 x LED (Audio Level, Power)
1 x LED (Battery Status)
1 x LED (Recharging)
Housing ABS, Plastic
Operating Temperature  0 to 50°C
Storage Temperature - -20 to 50°C
Dimensions  6.3 x 4.3 x 1.7 cm
Weight  34 g

Microphone
Form Factor Lavalier
Color Black
Sound Field Mono
Operating Principle Pressure Operated
Capsule Electret Condenser
Polar Pattern Omnidirectional
Frequency Range 50 Hz to 18 kHz
Equivalent Noise Level 58 dB
Maximum SPL 110 dB SPL
Sensitivity -30 dB
Output Connectors 1 x 1/8" / 3.5 mm TRS Male Unbalanced
Cable Length 1.22 m
Operating Voltage 1 V

Microphone 2
Form Factor Integrated
Sound Field Mono
Operating Principle Pressure Operated
Capsule Electret Condenser
Polar Pattern Omnidirectional
Frequency Range 50 Hz to 18 kHz
Equivalent Noise Level 58 dB
Maximum SPL 120 dB SPL
Sensitivity -42 dB
