Wireless Technology Analog UHF

Number of RF Channel Frequencies 1680

Included Transmitters 1 x Bodypack with Microphone

Diversity Antenna Diversity

RF Frequency Band A: 516 to 558 MHz

RF Bandwidth 42 MHz

Frequency Step Size 25 kHz

Max Operating Range 100.6 m (Line of Sight)

Max Transmitters per Band 12

Deviation 48 kHz (Peak)

Modulation   Wideband FM

Receiver

Receiver Type Camera-Mount

Mounting Options Shoe-Mount (with Included Hardware)

Antenna 1 x Flexible Whip, Fixed

Number of Audio Channels 1

Audio I/O 1 x 1/8" / 3.5 mm TRS Female Unbalanced Output (Lockable)

Gain Range 42 dB (6 dB Steps)

Audio Output Level +12 dBu

Squelch 5 to 25 dBμV

Adjacent Channel Isolation >65 dB

Power Requirements Battery

Battery Type 2 x AA (Included)

1 x Sennheiser Accupack (Not Included)

Approx. Battery Life 8 Hours (Alkaline)

Display & Indicators 1 x Backlit LCD (Battery Status, Output Level, RF Level)

Housing Metal

Operating Temperature -10 to 55°C

Dimensions  64 x 82 x 24 mm

Weight  160 g (with Batteries)

Transmitter

Transmitter Type Bodypack

RF Output Power 30 mW

Audio I/O 1 x 1/8" / 3.5 mm TRS Female Unbalanced Input (Lockable)

Muting Mute Switch

Audio Input Level 3 V RMS (Max)

Gain Range 60 dB (3 dB Steps)

Frequency Response 80 Hz to 18 kHz (Mic)

25 Hz to 18 kHz (Line)

Sync Method IR

Antenna 1 x Flexible Whip, Fixed (Beltpack)

Power Requirements Battery

Battery Type 2 x AA (Included)

1 x Sennheiser Accupack (Not Included)

Approx. Battery Life 8 Hours (Alkaline)

Display & Indicators 1 x Backlit LCD (Audio Level, Battery Status, Signal Strength)

Housing Metal

Dimensions  64 x 82 x 24 mm

Weight  160 g (with Batteries)

Microphone

Microphone Type Lavalier

Sound Field Mono

Operating Principle Pressure Gradient

Capsule Electret Condenser

Polar Pattern Cardioid

Frequency Range 50 Hz to 18 kHz

Equivalent Noise Level 31 dB

Maximum SPL 120 dB SPL Peak

Sensitivity 20 mV/Pa

Output 1 x / 3.5 mm TRS Male Unbalanced (Lockable)

Cable Length /1.6 m

Operating Voltage 7.5 V
