Input

Video Inputs 2 x HDMI

4 x BNC (3G-SDI)

Input Video Format HDMI (8/10/12-Bit 4:4:4/4:2:2 RGB, YUV)

1080p at 23.98/24/25/29.97/30/50/59.94/60 fps

1080i 50/59.94/60 fps

720p 23.98/24/25/29.97/30/50/59.94/60 fps

576p 50 fps

576i / 625 lines 50 fps

SDI (10-Bit 4:2:2 YUV)

1080p at 23.98/24/25/29.97/30/50/59.94/60 fps

1080i 50/59.94/60 fps

1080PsF 23.98/24/25/29.97/30 fps

720p 23.98/24/25/29.97/30/50/59.94/60 fps

Audio Inputs 1 x 1/8" / 3.5 mm TRS Stereo

1 x 2RCA Analog

Output

Video Outputs 1 x HDMI (Program)

2 x BNC (3G-SDI) (Program)

1 x USB-C

Output Video Format HDMI / SDI

1080p at 24/25/30/50/60 fps

1080i 50/60 fps

USB-C

WUXGA (1920 x 1200)

1080p

WUXGA+ (1680 x 1050)

UXGA (1600 x 1200)

WXGA+ (1440 x 900)

FWXGA (1366 x 768)

SXGA (1280 x 1024)

1280 x 960

WXGA (1280 x 800)

1280 x 720 (Non-Standard WXGA)

XGA (1024 x 768)

1024 x 576

960 x 540

856 x 480

SVGA (800 x 600)

576i / 625 lines

720 x 480

VGA (640 x 480)

640 x 360

Audio Outputs 1 x 1/8" / 3.5 mm TS Stereo

1 x 2RCA Analog

Multiview Output 6-Way Multiview viaHDMI, SDI

Connectivity

Other I/O 1 x BNC Output

1 x DE-15/DB-15 Tally

1 x RJ45 LAN

Video Standard Compliance SMPTE 259M/292M/424M

Display

Display Size 13.3"

Screen Resolution 1920 x 1080

Hardware

OS Compatibility Windows 10

Windows 8

Windows 7

macOS 10.8 or Later

Linux 2.6.38 or Later

*As of March, 2021: Check with manufacturer for the most up-to-date compatibility

Wi-Fi None

Bluetooth None

Power

Power I/O 1 x Barrel (12 VDC at 2 A) Input

Power Consumption 25 W

Environmental

Operating Temperature -20 to 60°C

Storage Temperature  -30 to 70°C

Operating Humidity 20 to 70%
