Specifications
Wireless
Wireless Range 90 m (Line-of-Sight)
120 m (Line-of-Sight)
Channel Bandwidth 20 MHz
Frequency Range 5 GHz
Latency < 0.1 sec
RF Power ≤ 21 dBm
RF Sensitivity -80 dBm
Wireless Video Compression Uncompressed

Interfaces
Transmitter Antenna Ports 2 x RP-SMA Female
Transmitter Video Connectors 1 x HDMI Input
1 x HDMI Loop Output
Receiver Video Connectors 2 x HDMI Output
Transmitter Other I/O 1 x USB Type-C Input
Receiver Other I/O 1 x USB Type-C Input
Embedded Audio HDMI: 2-Channel

Format Support
Video Format HDMI:
1080p at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps
1080i at 50, 59.94, 60 fps
720p at 50, 59.94, 60 fps
576p at 50 fps
480p at 60 fps
Timecode No

Display
Transmitter Panel Type OLED
Receiver Panel Type OLED

Power
Transmitter Battery Support 1 x Sony L-Series / NP-F Type
Receiver Battery Support 1 x Sony L-Series / NP-F Type
Transmitter Power Connector 1 x USB Type-C (5 VDC at 2 A) Input
Receiver Power Connector 1 x USB Type-C (5 VDC at 2 A) Input
Transmitter Power Consumption Device: 5 to 12 VDC (11 W)
Receiver Power Consumption Device: 5 to 12 VDC (6 W)

General
Transmitter Mounting 1 x 1/4"-20 Female
Receiver Mounting 1 x 1/4"-20 Female
Transmitter Dimensions  10.6 x 6.1 x 2.2 cm (Without Battery Plate)
Receiver Dimensions 11 x 6.1 x 2.1 cm
Transmitter Weight 172.5 g
Receiver Weight  189 g
