Specifications

Inputs 1x SDI: Detects & auto-switches between SD-, HD-, and 3G-SDI

Outputs 8x SDI: Automatically match the SDI video input

Re-clocking Yes

Supported Formats NTSC, PAL, 720p, 1080i, 1080PsF, 1080p, 2K p, and 2K PsF

SDI Compliance SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, and SMPTE 425M

Video Sampling 4:2:2 and 4:4:4

Audio Sampling Television standard sample rate of 48 kHz and 24-bit

Color Precision 4:2:2 and 4:4:4

Color Space YUV and RGB

ASI Support Yes

Power Supply 12V universal power supply included

Power Consumption 110V: 40mA, 220V: 20mA

Voltage Range 12-30V
