Specification
Host Connection PCIe (Length Unspecified)

Input
Video Input Connectors 1 x BNC (3G-SDI / HD-SDI / SD-SDI)
1 x HDMI (HDMI 2.0)
Input Video Format SDI (8/10/12-Bit 4:4:4 RGB)
1080p at 23.98/24/25/29.97/30 fps
720p at 50/59.94/60 fps
576i / 625 lines at 50 fps
480i / 525 lines at 59.94 fps
SDI (8/10-Bit 4:2:2 YUV)
DCI 2K at 23.98/24/25/29.97/30/50/59.94/60 fps
DCI 2KPsF at 23.98/24/25/29.97/30 fps
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080PsF at 23.98/24/25/29.97/30 fps
1080i at 50/59.94/60 fps
576i / 625 lines at 50 fps
480i / 525 lines at 59.94 fps
HDMI (8-Bit 4:4:4 RGB, YUV)
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080i at 50/59.94/60 fps
720p at 50/59.94/60 fps
576i / 625 lines at 50 fps
480i / 525 lines at 59.94 fps
HDMI (12-Bit 4:4:4 YUV)
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080i at 50/59.94/60 fps
720p at 50/59.94/60 fps
576i / 625 lines at 50 fps
480i / 525 lines at 59.94 fps
Simultaneous Multi-Input Support Not Specified by Manufacturer
Audio Input Connectors None
Embedded Audio Input SDI: 16-Channel
HDMI: 8-Channel

Output
Embedded Audio Output: None
Standards
Video Standard Compliance SMPTE 259M/274M/296M/424M/425M-A/425M-B/ST-2108-1
HDR Compatibility Not Specified by Manufacturer

Hardware
OS Compatibility macOS 11.1
macOS 12.0 or Later
Windows 10
Windows 11
Linux
*As of July, 2022: Check with manufacturer for the most up-to-date compatibility
Power Consumption Device: 3 W

Environmental
Operating Temperature: 5 to 40°C
Storage Temperature: -20 to 45°C
Operating Humidity: 0 to 90% (Non-Condensing)
Storage Humidity: 0 to 90% (Non-Condensing)
