Specifications
Mix Effects
Available M/E Layers 9 M/E
Effect Types 2 x DVE, 4 x Luma Key, 4 x Chroma Key
Graphics Memory 20 Images
Downstream Keys 2 x Chroma, Luma, DVE
Generators 5 x Pattern, 2 x Color
Audio Mixing 2-Channel Mixing

Processing
Switching Type Pushbutton, Software
Processing Resolution 1080p

Input
Number of Video Input Sources 8
Video Input Connectors 8 x HDMI
Input Video Format HDMI (10-Bit 4:2:2 YUV)
1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
1080i: 50/59.94/60 fps
720p: 50/59.94/60 fps
Audio Input Connectors 2 x 1/8" / 3.5 mm TRS Stereo Analog Female
Input Audio Format Analog
Embedded Audio Input HDMI: 2-Channel (per Input)

Output
Video Output Channels 2
Video Output Connectors 2 x HDMI
Output Video Format HDMI (10-Bit 4:2:2 YUV)
1080p: 23.98/24/25/29.97/30/50/59.94/60 fps
Audio Output Connectors 1 x 1/8" / 3.5 mm TRRS Headphone/Microphone Stereo Analog Female
Embedded Audio Output HDMI: 2-Channel
Multiview Output 16-Way Multiview viaHDMI

Connectivity
Other I/O 1 x RJ45, 2 x USB Type-C
HDCP Support None
IP Encoding/Decoding
IP Video H.264:, 1920 x 1080 Encoding
Transport Protocols RTMP
Simultaneous Streams 1 Streams
Internal Recording
Recording Modes 1920 x 1080p up to 60 fps (MP4)

Hardware
OS Compatibility macOS 10.15, macOS 11.1 or Later, Windows 10

Power
Power Connector 1 x Barrel (12 VDC) Input
Power Consumption Device: 36 W

Environmental
Operating Temperature 41 to 104°F / 5 to 40°C
Storage Temperature 14 to 140°F / -10 to 60°C
Operating Humidity 0 to 70%

General
Dimensions  36.98 x 13.64 x 3.96 cm
Weight 1.23 kg
