Specifications

Input
Video Input Connectors 1 x BNC (3G-SDI / HD-SDI / SD-SDI)
Input Video Format SDI (8/10-Bit 4:2:2 RGB, YUV)
DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
DCI 2KPsF 25/29.97/30 fps
1080p 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080PsF 25/29.97/30 fps
1080i 50/59.94/60 fps
720p 50/59.94/60 fps
NTSC 59.94 fps
PAL 50 fps
Audio Input Connectors None
Embedded Audio Input SDI

Output
Video Output Connectors 1 x BNC (3G-SDI / HD-SDI / SD-SDI) (Loop Output)
1 x HDMI
Output Video Format SDI (8/10-Bit 4:2:2 RGB, YUV)
DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
DCI 2KPsF 25/29.97/30 fps
1080p 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080PsF 25/29.97/30 fps
1080i 50/59.94/60 fps
720p 50/59.94/60 fps
NTSC 29.97 fps
PAL (768 x 576) 25 fps
HDMI (8/10-Bit 4:2:2 RGB, YUV)
1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080i 50/59.94/60 fps
720p 50/59.94/60 fps
NTSC 29.97 fps
PAL (768 x 576) 25 fps
Audio Output Connectors None
Embedded Audio Output HDMI, SDI

Standards
Video Standard Compliance SMPTE 259M/292M/296M/424M/425M-A/425M-B
HDCP Support Version 2.2

Connectivity
Other I/O 1 x USB Type-C Input
Expansion Slots None
Hardware
Tally Light Yes
OS Compatibility macOS 10.14.15 or Later
Windows 10

Power
Power Connector 1 x USB Type-C (4.4 to 5.2 VDC) Input
Power Consumption 2.5 W
