Specifications

Video Input 1 x HDMI, Type A

Video Output 2 x 6G-SDI

Multi-Rate Support Auto detection of SD, HD, 3G, or 6G-SDI signals

Reclocking Yes

Audio Input Analog: 2 channels with 1 x 1/4" jack per channel

AES/EBU: 4 channels with 1 x 1/4" jack

Format Support DCI 4K 24p UHD 4K

3840 x 2160p: 30/29.97/25/24/23.98

HD

1080p: 60/59.94/50/30/29.97/25/24/23.98

1080i: 60/59.94/50

720p: 60/59.94/50

SD

NTSC: 525i/59.94

PAL: 625i/50

SDI Compliance SMPTE 259M/292M/296M/372M/424M/425M Level A or B/SMPTE ST-2081

ITU-R BT.656 and ITU-R BT.601

SDI Video Rates Switchable between SD, HD, Ultra HD and DCI 4K

SDI Video Sampling 4:2:2

SDI Color Precision 4:2:2

SDI Color Space YUV

SDI Audio Sampling 24-bit, 48 kHz

SDI Auto Switching Automatically detects SD, HD, or 6G-SDI

HDMI Format Support UHD 4K

3840 x 2160p: 30/29.97/25/24/23.98

HD

1080p: 60/59.94/50/30/29.97/25/24/23.98

1080i: 60/59.94/50

720p: 60/59.94/50

SD

NTSC: 525i/59.94

PAL: 625i/50

HDMI Color Space YUV and RGB

HDMI Color Precision 4:2:2

4:4:4

HDCP Compliance No. HDMI input is unable to capture from copy-protected HDMI sources

Format Conversion HD down-conversion

Settings Control Mini switches or USB software

Firmware Upgradeable Via USB

Power Supply 12 VDC

Power Consumption 4.44 W

Operational Voltage Range 12 to 31 VDC

Operating Temperature 0 to 40 °C

Storage Temperature  -20 to 45 °C

Relative Humidity 0 to 90% non-condensing

Dimensions  11.40 x 9.22 x 2.29 cm

Weight 243.8 g
