Specifications

Input
Video Input Connectors 1 x BNC (3G-SDI / HD-SDI / SD-SDI)
1 x HDMI (HDMI 2.0)
Input Video Format SDI (8/10-Bit 4:2:2 RGB, YUV)
DCI 2K: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
DCI 2KPsF: 25/29.97/30 fps
1080p: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080PsF: 25/29.97/30 fps
1080i: 50/59.94/60 fps
720p: 50/59.94/60 fps
NTSC: 59.94 fps
PAL: 50 fps
HDMI (8/10-Bit 4:2:2 RGB, YUV)
1080p: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080i: 50/59.94/60 fps
720p: 50/59.94/60 fps
NTSC: 29.97 fps
PAL: 25 fps
Audio Input Connectors None
Embedded Audio Input HDMI, SDI

Output
Video Output Connectors 1 x BNC (3G-SDI / HD-SDI / SD-SDI)
1 x HDMI (HDMI 2.0)
Output Video Format SDI (8/10-Bit 4:2:2 RGB, YUV)
DCI 2K: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
DCI 2KPsF: 25/29.97/30 fps
1080p: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080PsF: 25/29.97/30 fps
1080i: 50/59.94/60 fps
720p: 50/59.94/60 fps
NTSC: 29.97 fps
PAL (768 x 576): 25 fps
Audio Output Connectors None
Embedded Audio Output HDMI, SDI

Standards
Video Standard Compliance SMPTE 259M/292M/296M/424M/425M-A/425M-B
HDCP Support Version 2.2

Connectivity
Other I/O 1 x USB Type-C Input
Expansion Slots None

Hardware
Tally Light Yes
OS Compatibility macOS 10.14.15 or Later, Windows 10

Power
Power Connector 1 x USB Type-C (4.4 to 5.2 VDC) Input
Power Consumption 2.5 W

Environmental
Operating Temperature  0 to 40°C
Storage Temperature  -20 to 60°C
Operating Humidity 0 to 90%

General
Dimensions  80.77 x 58.93 x 24.89 mm
Weight  174 g
