Specifications

Input

Video Input Connectors 1 x HDMI (HDMI 2.0)

Input Video Format HDMI (8/10-Bit 4:2:2 RGB, YUV)

1080p: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

1080i: 50/59.94/60 fps

720p: 50/59.94/60 fps

NTSC: 29.97 fps

PAL: 25 fps

Audio Input Connectors None

Embedded Audio Input HDMI

Output

Video Output Connectors 2 x BNC (3G-SDI / HD-SDI / SD-SDI)

Output Video Format SDI (8/10-Bit 4:2:2 RGB, YUV)

DCI 2K: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

DCI 2KPsF: 25/29.97/30 fps

1080p: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

1080PsF: 25/29.97/30 fps

1080i: 50/59.94/60 fps

720p: 50/59.94/60 fps

NTSC: 29.97 fps

PAL (768 x 576): 25 fps

Audio Output Connectors None

Embedded Audio Output SDI

Standards

Video Standard Compliance SMPTE 259M/292M/296M/424M/425M

HDCP Support Version 2.2

Connectivity

Other I/O 1 x USB Type-C Input

Expansion Slots None

Hardware

OS Compatibility macOS 10.14.15 or Later, Windows 10

Power

Power Connector 1 x USB Type-C (4.4 to 5.2 VDC) Input

Power Consumption 2 W

Environmental

Operating Temperature 0 to 40°C

Storage Temperature  -20 to 60°C

Operating Humidity 0 to 90%

General

Dimensions  76.45 x 45.7 x 24.89 mm

Weight  150 g
