Specifications

Interfaces

Output Connectors 1 x BNC (6G-SDI)

1 x HDMI

4 x BNC (6G-SDI, Looping)

Other I/O 1 x RJ45

1 x USB Type-A USB 2.0

Standards

Video Standard Compliance SMPTE 259M/292M/296M/310M/425M-B

ITU -R BT.601/BT.656

Reclocking Yes

Transmission

Video Format SDI (10-Bit 4:4:4/4:2:2 RGB, YUV)

DCI 4K: 24 fps

UHD 4K: 23.98/24/25/29.97/30 fps

DCI 2KPsF: 23.98/24/25 fps

DCI 2K: 23.98/24/25 fps

1080p: 23.98/24/25/29.97/30/50/59.94/60 fps

1080PsF: 23.98/24/25/29.97/30 fps

1080i: 50/59.94/60 fps

720p: 50/59.94/60 fps

NTSC: 29.97 fps

PAL: 25 fps

Max Sample Rate/Resolution 48 kHz / 24-Bit

Maximum Data Rate 6 Gb/s

Power

Power Consumption 90 to 240 VAC (16 W)

Environmental

Operating Temperature  0 to 40°C

Storage Temperature  -20 to 45°C

Operating Humidity 0 to 90%
