IP Encoding/Decoding

IP Video H.264:

960 x 540 to 1920 x 1080 Encoding

IP Audio AAC-LC: Encoding

Transport Protocols RTMP

Simultaneous Streams 3 Streams

Compatible Services Facebook Live, Twitch, YouTube Live

Wireless

Wi-Fi Yes

Bluetooth None

Cellular

SIM Card Slots 1 x Nano SIM

4G LTE LTE

Interfaces

Video I/O 1 x HDMI Input

1 x HDMI Output

Audio I/O 1 x 1/8" / 3.5 mm TRS Stereo Analog Input

3.5 mm TRS Mono Analog Input

3.5 mm TRRS Headphone/Microphone Stereo Analog Output

Other I/O 1 x RJ45 (10/100 Ethernet) Input/Output

1 x USB-A 3.0 / 3.1/3.2 Gen 1 Input

1 x USB-C 3.0 / 3.1/3.2 Gen 1 Input/Output

Embedded Audio HDMI/Wireless: 2-Channel

Internal Recording

Recording Media 1 x SD (Unspecified Type)

Recording Modes 1920 x 1080p up to 60 fps

Power

Built-In Battery 4700 mAh

Power Connector 1 x USB-C (5 to 12 VDC at 1.5 A) Input

Environmental

Operating Temperature 0 to 40°C

Operating Humidity 15 to 85%

Storage Temperature  5 to 40°C

General

Display LCD

Dimensions  155 x 92.6 x 20 mm
