Specifications

I/O
Inputs 12G/HD/SD-SDI: 8 x BNC
Audio: 2 x 3-Pin XLR
Reference: 1 x BNC
Outputs 12G/HD/SD-SDI: 8 x BNC
Auxiliary: 1 x BNC
Program: 1 x BNC
Multiview: 1 x BNC
Multiview: 1 x HDMI
Headphone: 1
Other 1 x RS-422
1 x Ethernet
1 x USB 2.0
1 x AC Power In
1 x 4-pin XLR Power In

Standards
Format Support UHD Video:
2160p: 59.94/50/29.97/25/24/23.98
HD Video:
1080p: 59.94/50/29.97/25/24/23.98
1080i: 59.94/50
720p: 59.94/50
Input Resolutions for Computers
2160p: 59.94/50/30/29.97/25/24/23.98
1080p: 59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 59.94/50
SDI Compliance 292M, 424M
2081, 2082
Video Sampling 4:2:2, 10-Bit
Color Precision 4:2:2, 10-Bit
Color Space 4:2:2 YUV
Color Space Conversion None
Processing Delay 6 Lines

General
Audio Mixer 12-Input x 2-Channel Mixer
Keyers Upstream: 1 with Chroma/Linear/Luma Key
Downstream: 2
Chroma: 1
Linear/Luma: 3
Transition (Stinger/DVE): 1
Layers Up to 5
Generators Pattern: 2
Color: 2
DVE Border and Drop Shadow: 1
Number of Windows Multiview: 1 x 10
Routable: 8
Fixed, Program, and Preview: 2
Media Player Players: 2 (Non-Volatile Flash Memory)
Media Pool Still Image Capacity: 20 (with Fill and Key)
Media Pool Still Image Format: PNG, TGA, BMP, GIF, JPEG, TIFF
Channels: Fill and Key for Each Media Player
Media Pool Clip Capacity: 2 (with Fill and Key / Shared Pool)
Media Pool Clip File Format: TGA Sequence
Media Player Clip Length:
UHD 4K: 90 Frames
1080 HD: 360 Frames
720 HD: 1440 Frames
Media Pool Audio File Format: WAV, MPE, AIFF
Compatible Operating Systems MacOS 10.12 Sierra, MacOS High Sierra 10.13 or Higher
Windows 8.1 or 10
Power Supply AC: 110-240 VAC Internal
DC: 1 x 4-Pin XLR
Power Draw 70 W
Environmental Operating: 5 to 40°C
Storage:  -20 to 60°C
Relative Humidity: 0 to 90% Non-Condensing
