Specifications

Imaging

Lens Mount: Canon RF

Included Lens Mount Adapter: Canon EF

Lens Communication: Yes, with Autofocus Support

Sensor Resolution Effective: 19.9 Megapixel (6144 x 3240)

Sensor Type: 27.03 x 14.26 mm (Super35) CMOS

Sensor Crop While Recording:

 5K (5120 x 2700) in 17:9 When Recording in Raw

4K (4096 x 2160) in 17:9 When Recording in Raw

2K (2048 x 1080) in 17:9 When Recording in Raw

Built-In ND Filter: None

Shutter Type: Electronic Global Shutter

Advertised Dynamic Range 16 Stops

Internal Recording

Raw Recording: REDCODE RAW

6144 x 3240 up to 40 fps [280 MB/s]

5120 x 2700 up to 48 fps [280 MB/s]

4096 x 2160 up to 60 fps [280 MB/s]

2048 x 1080 up to 119.88 fps [280 MB/s]

Recording Modes: ProRes 422/ProRes 422HQ:

4096 x 2160p up to 60 fps

ProRes 422:

2048 x 1080p up to 120 fps

Audio Recording: 2-Channel 24-Bit 48 kHz

Still Image Support: Not Specified by Manufacturer

External Recording

Video Output: 4:2:2 10-Bit via SDI/BNC:

4096 x 2160p at 23.98/24/25/29.97/30/50/59.94/60 fps

3840 x 2160p at 23.98/24/25/29.97/30/50/59.94/60 fps

2048 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps

1920 x 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps

Interface

Media/Memory Card Slot: Single Slot: CFast (CFast 2.0)

Video I/O 1 x BNC (12G-SDI) Monitor Output

Audio I/O 1 x 1/8" / 3.5 mm TRS Stereo Microphone Input

Built-In Microphone Type: Stereo

Other I/O 1 x 9-Pin (GPI, Genlock, RS-232, Timecode)

Wireless: 2.4 / 5 GHz Wi-Fi 5 (802.11ac) Video Output, Control

Monitor

Size: 2.9"

Resolution: 1440 x 1440

Display Type: Fixed Touchscreen LCD

Power

Battery Type Canon: BP-9 Series

Power I/O: 1 x 2-Pin LEMO (7 to 17 VDC) Input

Power Consumption: 45 W
