Image Sensor
Sensor
Full Frame Back Side Illuminated
(BSI) CMOS sensor
System
RGB primary color filter (Bayer array)
Sensor Modes
Full Frame / Super 35mm (Crop) /
Super 16mm (Crop)
Total Pixels
Approx. 26.67 megapixels (6202 x 4300)
Effective Pixels Approx. 19.05 megapixels (6008 x 3170): When
6000 x 3164 / 4096 x 2160 / 2048 x 1080 is selected as the resolution
Approx. 17.86 megapixels (5633 x 3170)：When
3840 x 2160 / 1920 x 1080 is selected as the resolution
Effective Sensor Screen Size
Full Frame: 38.4 x 20.2 mm (40.7 mm on the diagonal)：
When 6000 x 3164 / 4096 x 2160 / 2048 x 1080 is selected as the resolution
36.0 x 20.2 mm (38.7 mm on the diagonal)：When
3840 x 2160 / 1920 x 1080 is selected as the resolution

Dynamic Range
Canon Log 2: 1600% / 16 stops (at ISO 800)
Canon Log 3：1600% / 14 stops (at ISO 800)
Base ISO : 800 / 3200 / 12800

Image Processor
Type DIGIC DV7

Lens
Lens Mount
Canon RF mount
PL mount support via PL - RF Mount Adapter
EF mount support via EF - EOS R Mount Adapters
Lens Magnification Factor
Full Frame;
4096 x 2160 or 2048 x 1080 : Actual focal length x Approx. 1.06
3840 x 2160 or 1920 x 1080 : Actual focal length x Approx. 1.12
Super 35mm (Crop); 4096 x 2160 or 2048 x 1080 : Actual focal length x Approx. 1.46
3840 x 2160 or 1920 x 1080 : Actual focal length x Approx. 1.54
Super 16mm (Crop); 2048 x 1080 : Actual focal length x Approx. 2.92 1920 x 1080 :
Actual focal length x Approx. 3.07
Digital Lens Correction
Peripheral Illumination Correction
Chromatic Aberration Correction
Diffraction Correction
Distortion Correction (RF lenses only)
ND Filter
2, 4 or 6 Stops. Up to 10 stops via built in ND filter system (in extended mode)
Iris Control (EF Mount Lenses)
1/2 - stop, 1/3 - stop or
FINE control
Auto Iris
Cooke / i Technology Support
Only when equipped with Mount Adapter PL-RF
Anamorphic Lens Support
x2.0 / x1.8 / x1.3
Image Stabilization System
5-Axis Combination IS (Optical and Digital) with supported lenses
Digital 5-Axis IS for non IS lenses.

Recording
Internal Recording Media 1
1x CFexpress 2.0 (Type-B)
1x SD Card (SD / SDHC / SDXC)
Recording Time 2
Cinema RAW Light LT : 6000 x 3164 576 Mbps : approx. 118 Mins
Cinema RAW Light ST : 6000 x 3164 886 Mbps : approx. 77 Mins
Cinema RAW Light HQ : 6000 x 3164 1800 Mbps : approx. 37 Mins
XF-AVC : 4096 x 2160 500 Mbps : approx. 136 Mins
XF-AVC S : 4096 x 2160 500 Mbps :approx. 136 Mins
XF-HEVC S : 4096 x 2160 135 Mbps :approx. 505 Mins
Recording Formats
Cinema RAW Light (CRM), XF-AVC (MXF),XF-AVC S (MP4), XF-HEVC S (MP4)
Relay Recording 3
Yes
Double Slot (Simultaneous) Recording Yes
Simultaneous Recording in Multiple Formats Yes
System Frequency / Frame Rates
59.94 Hz mode (59.94P / 59.94i / 29.97P / 23.98P)
50.00 Hz mode (50.00P / 50.00i / 25.00P)
24.00 Hz mode (24.00P)
Cinema RAW Light Bit Rate / Bit Depth (PAL)
12-bit Cinema RAW Light LT
FF / 6000 x 3164 / 50P [1160 Mbps]
FF / 6000 x 3164 / 25P [576 Mbps]
S35 / 4368 x 2304 / 50P [611 Mbps]
S35 / 4368 x 2304 / 25P [306 Mbps]
S16 / 2184 x 1152 / 50P [154 Mbps]
S16 / 2184 x 1152 / 25P [77 Mbps]
12-bit Cinema RAW Light ST
FF / 6000 x 3164 / 50P [1780 Mbps]
FF / 6000 x 3164 / 25P [886 Mbps]
S35 / 4368 x 2304 / 50P [939 Mbps]
S35 / 4368 x 2304 / 25P [470 Mbps]
S16 / 2184 x 1152 / 50P [236 Mbps]
S16 / 2184 x 1152 / 25P [118 Mbps]
12-bit Cinema RAW Light HQ :
FF / 6000 x 3164 / 25P [1800 Mbps]
S35 / 4368 x 2304 / 50P [1910 Mbps]
S35 / 4368 x 2304 / 25P [954 Mbps]
S16 / 2184 x 1152 / 50P [479 Mbps]
S16 / 2184 x 1152 / 25P [240 Mbps]
XF-AVC Recording Bit Rate / Sampling (PAL / MXF)
4:2:2 10-bit (Intra-frame)
4096 x 2160 or 3840 x 2160 / 50P
[1000 / 750 / 500 Mbps]
4096 x 2160 or 3840 x 2160 / 25P
[500 / 375 / 250 Mbps]
2048 x 1080 or 1920 x 1080 / 50P [250 Mbps]
2048 x 1080 or 1920 x 1080 / 50i [125 Mbps]
2048 x 1080 or 1920 x 1080 / 25P [125 Mbps]
4:2:2 10-bit (Long GOP)
4096 x 2160 or 3840 x 2160 / 50P [250 Mbps]
4096 x 2160 or 3840 x 2160 / 25P [150 Mbps]
2048 x 1080 or 1920 x 1080 / 50P [50 Mbps]
2048 x 1080 or 1920 x 1080 / 50i [50 / 25 Mbps]
2048 x 1080 or 1920 x 1080 / 25P [50 Mbps]
XF-AVC S Recording Bit Rate / Sampling (PAL / MP4)
4:2:2 10-bit (Intra-frame)
4096 x 2160 or 3840 x 2160 / 50P
[1000 / 750 / 500 Mbps]
4096 x 2160 or 3840 x 2160 / 25P
[500 / 375 / 250 Mbps]
2048 x 1080 or 1920 x 1080 / 50P [250 Mbps]
2048 x 1080 or 1920 x 1080 / 25P [125 Mbps]
4:2:2 10-bit (Long GOP)
4096 x 2160 or 3840 x 2160 / 50P [250 Mbps]
4096 x 2160 or 3840 x 2160 / 25P [150 Mbps]
2048 x 1080 or 1920 x 1080 / 50P [50 Mbps]
2048 x 1080 or 1920 x 1080 / 25P [50 Mbps]
4:2:0 8-bit (Long GOP)
4096 x 2160 or 3840 x 2160 / 50P [150 Mbps]
4096 x 2160 or 3840 x 2160 / 25P [100 Mbps]
2048 x 1080 or 1920 x 1080 / 50P [35 Mbps]
2048 x 1080 or 1920 x 1080 / 25P [35 Mbps]
XF-HEVC S Recording Bit Rate / Sampling (PAL / MP4)
4:2:2 10-bit (Long GOP)
4096 x 2160 or 3840 x 2160 / 50P [225 Mbps]
4096 x 2160 or 3840 x 2160 / 25P [135 Mbps]
2048 x 1080 or 1920 x 1080 / 50P [50 Mbps]
2048 x 1080 or 1920 x 1080 / 25P [50 Mbps]
4:2:0 10-bit (Long GOP)
4096 x 2160 or 3840 x 2160 / 50P [150 Mbps]
4096 x 2160 or 3840 x 2160 / 25P [100 Mbps]
2048 x 1080 or 1920 x 1080 / 50P [35 Mbps]
2048 x 1080 or 1920 x 1080 / 25P [35 Mbps]
Proxy Recording Bit Rate / Sampling (PAL) 4
4:2:0 8-bit (Long GOP) :
2048 x 1080 or 1920 x 1080 35 / 16 / 9 Mbps]
1280 x 720 [6 Mbps]
4:2:0 10-bit (Long GOP) :
2048 x 1080 or 1920 x 1080 [16 / 9 Mbps]
Slow / Fast Motion 5
6K RAW : up to 60FPS
4K : up to 120FPS
4.3K RAW (S35 Crop) : up to 100FPS
2K (S16 Crop) : up to 180 FPS
Interval Record Yes
Frame Record Yes
Pre Record (Cache Record) 6
3 Seconds
Digital Tele-converter
1.5x, 2x, 2.5x, 3x, Off
Photo Storage Media
SD Card
Photo Recording Size 7
4096 x 2160 / 3840 x 2160 / 2048 x 1080 / 1920 x 1080

System
Display Type
3.5 inch LCD Touch Panel
Display Resolution
approx. 2.76 million dots (1280 x RGB x 720)
Display Touch Screen Functions
Focus Point Selection
Touch Screen UI for Shooting Settings
OSD for Vertical Shooting Yes
Wave Form Monitor
Yes (Line / Line + Spot / RGB Parade / YPrPb Parade)
False Colour Display (Exposure Indication)
Yes (6 Colour Index)
Colour Bars
SMPTE / EBU / ARIB
Peaking
Peaking 1, Peaking 2 (Colour, Gain, Frequency customisable)
Zebra
Level 1; Level 2; Both
Markers
On / Off selectable: centre, horizontal / vertical, grid,aspect,
safe area and user marker. Colour selectable
EVF:
Built-In EVF No

Inputs / Outputs
Audio In 2x Mini XLR 3-pin connector
1x 3.5 mm stereo mini jack
Built in Stereo microphones on camera body
Headphone Output 1x 3.5mm stereo mini jack
Video Monitor Output 1x 3G-SDI Output (BNC)
HDMI 1x HDMI (Type-A)
USB 1x USB-C Data Terminal (USB 3.2 Gen1)
SDI Output 1x 12G-SDI Output (BNC)
Time Code 1x DIN1.0 / 2.3 (Input / Output)
Genlock 1x DIN1.0 / 2.3 (shared with Sync & Return)
Sync 1x DIN1.0 / 2.3 (shared with Genlock & Return)
DC Input 12V (4-pin XLR / 11.5-20V)
Multi-Accessory Shoe Yes (via camera body or top handle)
Remote Control Terminal 1x 2.5 mm stereo mini jack
Lens Terminal 1x 12-pin jack
Ethernet Terminal 1x RJ45Connector (1000BASE-T compatible)
Grip 1x USB-C Terminal (for supplied Hand Grip only)
IP Streaming / FTP IP Streaming via Ethernet / Wi-Fi connection
9 Mbps / 4 Mbps: 1920 x 1080
(59.94p / 59.94i / 50.00p / 50.00i)
UDP / RTP / SRT / RTP+FEC / RTSP+RTP
User LUT Input Yes, in-built LUTs available for monitoring.
Custom LUTs can be applied directly to internal recordings via Look File function
(compatible with 17 or 33 grid .cube files)
Video Connector 1x USB-C Terminal (for supplied LCD Monitor only)
Tally Signal Yes, via Wi-Fi or Ethernet using XC Protocol
Return Signal Input 1x DIN1.0/2.3 (shared with Genlock & Sync)
User Assignable Buttons 13x (Body) / 3x (Hand Grip) / 2x (LCD Monitor)

Miscellaneous
Tally Lamp Yes, 2x
Custom Dial Yes, 3x
Software Application Support Cinema RAW Development
XF Utility
EOS VR Utility
Remote Camera Control Application
RAW Plugin for Avid Media Access
RAW Plugin for Final Cut Pro
XF Plugin for Avid Media Access
EOS VR Plugin for Adobe Premiere Pro
CV Metadata Plugin for Adobe After Effects
Live Link Plugin for Unreal Engine
CV Metadata Extraction Tool
MP4 Join Tool
HEVC Activator
Smartphone Application Support Canon Multi-Camera Control
Content Transfer Professional
Browser Remote Control
Exposure
Exposure Metering Standard / Spotlight / Backlight
Exposure Compensation AE shift function available. Target value (±8 steps from center)
Auto Exposure Mode Auto Iris / Auto ISO
Push Auto Iris Yes
Exposure Lock No
Auto Gain Control Setting Yes
ISO Sensitivity 8 1-Stop Display :
100* / 160** / 200 / 400 / 800 / 1600 / 3200 / 6400 /
12800 / 25600 / 51200 / 102400*
1/3-Stop Display :
100* / 125* / 160 / 200 / 250 / 320 / 400 / 500 / 640 /
800 / 1000 / 1250 / 1600 / 2000 / 2500 / 3200 / 4000 /
5000 / 6400 / 8000 / 10000 / 12800 / 16000 / 20000 /
25600 / 32000 / 40000 / 51200 / 64000* / 80000* /
102400*
*when ISO Extended Range is set to ON
**when ISO Extended Range is set to OFF
Auto Focus System Dual Pixel CMOS AF II + EOS iTR AF X
AF Frame Sizes Full: approx. 100% (Vertical) x approx. 100% (Horizontal)
Large Zone (Vertical) : Video display range approx. 97% (Vertical) x 25% (Horizontal)
Large Zone (Horizontal) : Video display range approx. 43% (Vertical) x 76% (Horizontal)
Zone: Video display range approx. 43% (Vertical) x 25% (Horizontal)
Small Zone : Video display range approx. 15.9% (Vertical) x 11.8% (Horizontal)
Auto Focus Modes Continuous AF / One-Shot AF
Face Detection AF Yes (Eye / Face / Head / Body)
Animal Detection AF Yes (Dogs / Cats)
Focus Guide Yes, with compatible Canon lenses
Gain Setting 9 -6dB*,-3dB*,-2dB**～48dB, 51dB*, 54dB*
*when ISO Extended Range is set to ON
**when ISO Extended Range is set to OFF
Shutter
Control Modes Speed / Angle / Clear Scan / Slow Shutter
Shutter Speed 1/1～1/2000 (total of 45 settings)
Shutter Angle 11.25º to 360º depending on frame rate
Slow Shutter (SLS) 1/3, 1/4, 1/6, 1/8, 1/12, 1/15, 1/25, 1/30 depending on frame rate
Clear Scan 23.97 Hz～2000 Hz depending on sensor mode / frame rate

Custom Picture
Stored Configurations C1 : Canon 709
C2 - Canon Log 2
C3 - Canon Log 3
C4 - BT.709 Wide DR
C5 - BT.709 Standard
C6 - PQ
C7 - HLG
C8 - EOS Standard
C9 - EOS Neutral
C10 - User10～User20
HDR-HLG Profile BT.2100 : Corresponds to ITU-R BT.2100
Vivid : Corresponds to Traditional Colour in ITU-R BT.2390
Colour Matrix Neutral Accurate colour reproduction
Production Camera Colour reproduction for use in movie production
Video Colour reproduction with contrast for TV broadcasts.
Image Adjustment Parameters Master Pedestal
Master Black
Black Gamma
Low Key Saturation
Knee
Sharpness
Noise Reduction
Skin Detail
Colour
Matrix Tuning
White Balance
Colour
Correction

Time Code
Count Up System Regen / RecRun / Free Run / External / Frame Count

Audio
Recording Format RAW / XF-AVC : Linear PCM (24-bit / 48 kHz, 4channels)
XF-AVC S / XF-HEVC S : Linear PCM (24-bit / 48 kHz,4 channels)
or MPEG2-AAC LC (16-bit 48kHz) 2 channels

Accessories
Supplied LCD Monitor
LCD Attachment Unit
MC-5U Monitor Cable
Handle Unit
Camera Grip
BP-A60N Battery Pack
CA-CP300 B Compact Power Adapter
CG-A20 Battery Charger
Microphone Holder
Optional BP-A60N / BP-A30N Battery Pack
BP-A30 / BP-A60 Battery Pack
CG-A20 / CG-A10 Battery Charger
CA-CP300 B Compact Power Adapter
MC-5U Monitor Cable
PL-RF Mount Adapter
EF-EOS R Mount Adapter
EF-EOS R Control Ring Mount Adapter
EF-EOS R Drop-In Filter Mount Adapter
EF-EOS R 0.71x Mount Adapter
Remote Camera Controller RC-V100
Remote Camera Controller RC-IP100
Remote Camera Controller RC-IP1000
DM-E1D Multi-Function Shoe Directional Stereo
Microphone OC-E4A Off-Camera Shoe Cord
IFC-100U / IFC-400U Interface Cable
Third Party Accessories Tascam CA-XLR2d XLR Microphone Adapter

Power Source
Power Supply (Battery) 10 BP-A60N (Supplied)
BP-A30N / BP-A30* / BP-A60* (Optional)
Power supply (Mains) DC IN 12V terminal : DC 11.5V-20V (4-pin XLR)
Power Consumption Cinema RAW Light: FF / 6K / 59.94P-32.5W
Cinema RAW Light: S35 / 4.3K / 59.94P-30.4W
XF-AVC: FF / 4K / 59.94P-31.6W
XF-AVC: FF / 2K / 59.94P-29.7W
Recording Time With supplied BP-A60N battery pack
Approx. 155-170mins (depending on recording mode)

Physical Specifications
Dimensions (Main Body Only) Approx. 142 x 135 x 135 mm
Weight (Body Only) Approx. 1540 g
Weight (Accessories) LCD Monitor: Approx. 155g
LCD Attachment Unit: 260g
MC-5U Monitor Cable: Approx. 25g
Handle Unit: Approx. 300g
Camera Grip: Approx. 270 g
BP-A60N Battery Pack: Approx. 465g
CA-CP300 B Compact Power Adapter: Approx. 219g
Battery Charger CG-A20: Approx. 145g
Microphone Holder + 2 screws: Approx. 60g
Operating Temperature Range Approx. 0 to 40°C, (85% relative humidity)
Approx.-5 to 45°C, (60% relative humidity)
