Specifications

Sensor Resolution
Actual: 20.9 Megapixel
Effective: 14 Megapixel
Image Sensor
13.2 x 8.8 mm (1"-Type) CMOS
Image Stabilization
Optical in Integrated Lens
Digital
ISO/Gain Sensitivity
Native: 250 to 16,000 to
Gain: -3 to 36 dB to dB
Internal Recording Modes
XAVC HS-L
UHD 4K (3840 x 2160) up to 23.98/50/59.94/100/120 fps [30 to 280 Mb/s]
XAVC S-I
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [240 to 600 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120/150/180/200/240 fps
XAVC S-L
3840 x 2160 at 23.98/25/29.97/50/59.94/100/120 fps [100 to 280 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120/150/180/200/240 fps
External Recording Modes
HDMI
3840 x 2160 at 23.98/25/29.97/50/59.94/100/120 fps
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120 fps
1920 x 1080i at 25/29.97/50/59.94/100/120 fps
Media/Memory Card Slot
Dual Slot: CFexpress Type A / SD (UHS-II)
Video I/O
1x HDMI (Unspecified Signal) Output
Mobile App Compatible
Yes: Android & iOS
Battery Type
Sony BP-U Series

Imaging
Sensor Resolution
Actual: 20.9 Megapixel
Effective: 14 Megapixel
Image Sensor
13.2 x 8.8 mm (1"-Type) CMOS
Image Stabilization
Optical in Integrated Lens
Digital
Built-In ND Filter
2 to 7 Stop Electronic ND Filter
Capture Type
Video Only

Exposure Control
Shutter Type
Electronic Rolling Shutter
Shutter Speed
1/8000 to 64 Seconds
ISO/Gain Sensitivity
Native: 250 to 16,000 to
Gain: -3 to 36 dB to dB
Shutter Angle
5.6 to 360°
Minimum Illumination
1.2 Lux
White Balance
Range: 2000 to 15,000K
Presets: ATW, Auto

Lens
Focal Length
7.71 to 154.21mm (35mm Equivalent: 24 to 480mm)
Optical Zoom Ratio
20x
Max Digital Zoom
1.5x ( in UHD 4K)
2x ( in 1080p)
Maximum Aperture
f/2.8 to 4.5
Minimum Focus Distance
0.4" / 1 cm
Filter Size
72 mm
Focus Control
Autofocus
Manual Focus

Video Capture
Internal Recording Modes
XAVC HS-L
UHD 4K (3840 x 2160) up to 23.98/50/59.94/100/120 fps [30 to 280 Mb/s]
XAVC S-I
3840 x 2160 at 23.98/25/29.97/50/59.94 fps [240 to 600 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120/150/180/200/240 fps
XAVC S-L
3840 x 2160 at 23.98/25/29.97/50/59.94/100/120 fps [100 to 280 Mb/s]
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120/150/180/200/240 fps
External Recording Modes
HDMI
3840 x 2160 at 23.98/25/29.97/50/59.94/100/120 fps
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120 fps
1920 x 1080i at 25/29.97/50/59.94/100/120 fps
Fast-/Slow-Motion Support
Yes
Gamma Curve
HDR-HLG, Rec709, S Cinetone, Sony S-Log 3
Built-In Microphone
Stereo
Audio Recording
4-Channel 24-Bit 48 kHz LPCM Audio
IP Streaming
H.264, H.265, RTMP, RTMPS, SRT
3840 x 2160
1920 x 1080
1280 x 720

Interface
Media/Memory Card Slot
Dual Slot: CFexpress Type A / SD (UHS-II)
Video I/O
1x HDMI (Unspecified Signal) Output
Audio I/O
2x XLR 3-Pin Input
1x 1/8" / 3.5 mm TRRS Headphone/Mic Headphone Output
1x 1/8" / 3.5 mm TRS Stereo Input
Power I/O
1x USB-C
Other I/O
1x 2.5 mm Sub-Mini (Remote) Control
1x RJ45 (LAN) Control
1x USB-C (USB 3.2 / 3.1 Gen 1)
Wireless
2.4 / 5 GHz Wi-Fi 5 (802.11ac)
Mobile App Compatible
Yes: Android & iOS
Global Positioning (GPS, GLONASS, etc.)
No

Monitor
Display Type
Primary Monitor: Articulating 3.5" Touchscreen LCD

Viewfinder
Type Electronic

Focus
Focus Mode
Automatic, Manual Focus
Autofocus Points
Phase Detection: 475

Power
Battery Type
Sony BP-U Series
Power Consumption
16 W

Environmental
Operating Conditions
32 to 104°F / 0 to 40°C
Storage Conditions
-4 to 140°F / -20 to 60°C

General
Shoe Mount
1x Intelligent Hot Shoe
Dimensions (W x H x D)
6.9 x 7.9 x 14.63" / 175.6 x 201.3 x 371.6 mm
Weight
4.25 lb / 1.93 kg (Body Only)

Packaging Info
Package Weight
10.3 lb
Box Dimensions (LxWxH)
18.8 x 11.9 x 11"
